Mounted bearings and housings
UKC305H ABC Ball bearing units

TYPE: Housing units, Cartridge units, Cast iron housing, Radial insert ball bearing with adapter sleeve, With inner ring extended on both sides

Metric Imperial Dimensions, mmin d 20,000 0,816 D 62,000 2,531 B 35,000 1,429 H 90,000 3,673 A 26,000 1,061 S 21,500 0,878 d3 38,000 1,551 Q M6x1 Weight, kg 1,500 Bearing UK305 + H2305 Housing C305 Adapter sleeve H2305 Manufacturer: ABC Interchange: SNR UKC305H
