Mounted bearings and housings
SESPA207-22 ABC Ball bearing units

TYPE: Housing units, Plummer block, Narrow cast iron housing, Radial insert ball bearing with eccentric locking collar, With inner ring extended at one side, wide base, massive bearing units, stainless steel, inch size

Metric Imperial Dimensions, mmin d 34,925 1,426 D 72,000 2,939 B 38,900 1,588 L 108,000 4,408 H 95,000 3,878 A 48,000 1,959 J 82,600 3,371 H1 12,000 0,490 S 30,400 1,241 d3 55,600 2,269 h 47,600 1,943 m M10 Weight, kg lb 1,750 0,794 Bearing SES207-22 Housing SPA207 Manufacturer: ABC Interchange: SNR SESPA207-22
