Sprockets
PHS 100-1DSTB16 SKF ANSI sprockets
|
|
Dimensions, mmin |
| Pitch, p |
31,750
1,296
|
| Pitch diameter, PD |
162,738
6,642
|
| Dimensions bore, min |
19,050
0,778
|
| Dimensions bore, max |
63,500
2,592
|
| Hub, H |
127,000
5,184
|
| Thickness, T1 |
17,580
0,718
|
| Thickness, T2 |
50,800
2,073
|
| I |
178,562
7,288
|
| Number of teeth |
16 |
| Number of sleeve |
2517 |
|
|
